11 M Wire Flame Spray Gun

11 M Wire Flame Spray Gun
Send Inquiry
Product Code : 01
Brand Name : METAL COAT
Price And Quantity
  • Minimum Order Quantity
  • 1 Piece
  • Price Range
  • 50000.00 - 500000.00 INR
Product Description
Our 11M Wire Flame Spray Gun is mainly designed to run at higher speeds allowing the user to provide soft wire material to any substrate. It is easy for hand held operations due to wire feed thumb trigger. It is made from soft wire applications. This gun can be used for smaller jobs and cranking out wide area of applications almost easily. It sprays Soft Wire like Zinc, Lead, Tin, Aluminium, Babbitt of size 1/8"  5/32" & 3/16"  .It will not spray hard materials like Nickel, Bronze, Copper,  Stainless Steel or Bonderite. Various accessories increase its versatility including different Air Cap, Nozzle and Siphon plug configurations to give exceptional coating quality and economical operation. 11M Wire Flame Spray Gunis perfect for hand held, fixed and mobile applications.


Product Details:



Wire Feed

Air Turbine

Wire Size Standard

1/8 Inch (3.17mm)

Wire Size Optional

5/32 Inches (3.97mm), 3/16 Inches (4.76mm)

Gasses Used


Fuel Gas

Acetylene / LPG / Propane

Compressed Air

35 CFM FAD at 75 psi (5 bar)

Start Stop Operation

By thumb operated wire feed valve


  • Length: 6 inch / 1 foot / 2 feet / 3 feet
  • Pressure Rating: 10 Bar
  • Oxygen Hose Blue: 3+7 Mtrs.
  • Fuel Gas Hose Red: 3+7 Mtrs.
  • Air Hose Black : 7 Mtrs.


Extension Nozzles: Where deep bores are to be sprayed, our nozzles are available. These nozzles allow access of the spray at depths upto 1.1 Mtr., whilst straight and deflector air caps can be selected to direct the spray stream to the area required. Its typically used in spraying in internal diameter or hard to reach coating surfaces. Its installation is easy by removing the standard Air Cap Body and Siphon plug & replacing it with the extension. This can be done in about 1-2 minutes without any tools. Our nozzles are available in different lengths for both Oxy-Acetylene and Oxy-Propane Gun.

Air Control Unit: Coprises of air filter cum regulator for secondary filtration & regulating air flow to wire flame spray gun. An additional outlet gives connections for operator's helmet. Pressure Rating: 10 Bar

Hose Kit: Comprises of Hose to connect oxygen cylinder and fuel gas cylinder with flow meter to spray gun.

Gas Flow Meter: Our offered flow meter are recommended to use with Flame Spray Equipment. Ease of reading helps economic operation and fast fault diagnosis. The unit consist of separate flowmeter for both Oxygen and Fuel Gas supplies.

Air Flow Meter with Hose: It is a highly perfect rugged and reliable instrument for regulating and measuring the flow of compressed air in a wire combustion spray system.

Model: 3AFM (Air Flow Meter) Flow Unit in both NLPM & SCFM

Wire Control Unit: The Wire Reel Stand with Straightener is specifically designed to dispense wires for flame spraying. A wire straightener is included and the unit is capable of handling either reeled or loose coiled wire or spool.

Spray Booth: It is used for controlling sprayed dust and fumes when metallizing operation takes place. It carries away metal dust particles as well as heat. Duct work has adjustable pipe length as well as ball joint to fit individual requirement.

Metal Spray Wire: Standard materials wires such as Aluminium Alloy, Tin, Aluminium,  Tin Alloy, Nickel, Nickel Alloy, Zinc, Stainless Steel, Brass, Molybdenum, Monel, Copper & many more are available.


  • Metallizing Helmet
  • Air Breather
  • Helmet Air Conditioner
  • Ear Muff: Protect the operator from noise originating during thermal spray.
  • Protective Glass
  • Safety Mask
  • Hand Gloves
Trade Information
  • FOB Port
  • Delhi
  • Payment Terms
  • Telegraphic Transfer (T/T), Letter of Credit at Sight (Sight L/C), Letter of Credit (L/C), Cheque
  • Supply Ability
  • 10 Piece Per Week
  • Delivery Time
  • 1 Week
  • Main Export Market(s)
  • Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
  • Main Domestic Market
  • All India
