6PM-II Powder Flame Spray Gun

Product Description

The 6PM-II Spray Guns can be used to apply premium coatings to solve many surface problems including machine element repairs, dimensional restoration, corrosion protection, abradable and wear resistance. Economical to operate, the 6PM-II series guns have high spray rates with low gas consumption and high deposit efficiencies can be achieved. These guns are also simple to learn to operate and maintain.

The 6PM-II gun series is suitable for all purpose use in that it can apply a wide range of coating materials such as self-fluxing alloys, ceramics, self-bonding materials and conventional materials such as steels, stainless steels, bronze, aluminum and nickel alloys.

A consistent and accurate supply of powder is fed from the MPF-700 Powder Feeder to the gun allowing you to mount or manually spray in virtually any position without affecting the powder feed rates.

Product Details:

STANDARD ACCESSORIES

Air Jet Assembly
If additional workpiece cooling is required or if denser, harder coatings are desirable, the Air Jet Assembly is available. Designed for attachment to the front of the 6P-II gun, it injects high velocity air into the spray stream. Adjustable cooling tubes can be focused towards any part of the spray stream or directly onto the workpiece.

Extension Nozzle
The extensions come in 1 or 2 feet lengths, can be fitted with 80-45^oangular gas heads. Typical uses are internal diameter or hard to reach coating surfaces. Installation is simple by removing the Air Cap Body and Siphon plug and replacing with the extension. This can be done in about 1 - 2 minutes without tools.

305mm - 1 Feet
610mm - 2 Feet
