5PM-II Powder Flame Spray Gun

5PM-II Powder Flame Spray Gun
Send Inquiry
Product Code : 21
Price And Quantity
  • Minimum Order Quantity
  • 1 Piece
  • Price Range
  • 50000.00 - 500000.00 INR
Product Description

Since our establishment in the market, we are engaged in providing a supreme grade array of 5PM-II Powder Flame Spray Gun. It is attached with the sprayer machine for painting  ceilings, walls, and different equipments. By using premium grade components and latest techniques, provided gun is made with high precision by our deft professionals. Apart from this, clients can avail this 5PM-II Powder Flame Spray Gun from us at rock bottom prices.

Product Details:


310 mm (L) 305 mm (H) 125 mm (W)


2 Kg. Approx. without hoses and empty powder canister

Gases Consumption

Acetylene 13.5-31.5 NLPM,Hydrogen 90-144 NLPM,Oxygen 20-45 NLPM,Compressed air 0.85m3/min at4.5bar

The 5PM-II is a very economical and versatile, handheld, Powder Spray Gun for combustion powder spray that can be used to apply coatings for a variety of applications such as surface repairs, dimensional restoration, corrosion protection and wear resistance. With its built in powder feed canister, a thermal spray system utilizing the 5PM-II gun is an excellent choice for shops with occasional surfacing activity or when an economical investment is required. The 5PM-II is suitable for all-purpose use in that it can apply a wide range of coating products such as self-fluxing alloys, ceramics, self bonding items and conventional items such as steels, stainless steels, bronze, aluminum-based and nickel-based alloys. Designed for handheld operation, the 5PM-II is lightweight and employs a handle for operator comfort and safety. A tool post fixture is also included to rest the gun during work piece changeover or for machine-mount operation.

When a item is flame-sprayed, a new and different item is created. This is the reason that quality of coating depends upon quality of powder. A slight variation in powder chemistry can greatly influence the property of final coating.
The particle size distribution in a powder can affect the density and porosity of the coating. Our Powders meet tough standards on chemical composition, particle shape & size, flow rate & purity.

Air Jet Assembly
If additional workpiece cooling is required or if denser, harder coatings are desirable, the 2PSA Air Jet Assembly is available. Designed for attachment to the front of the 5P-II gun, it injects high velocity air into the spray stream. Adjustable cooling tubes can be focused towards any part of the spray stream or directly onto the workpiece.

For certain fine powders that are not freely flowing, the 5PM Vibrator is available in single phase 220V AC/110 VAC

Extension Nozzle
Extension Nozzle for the 5PM-II gun permit coating of interior bore diameters and surfaces, and are available in three standard lengths:
305mm - 1 Feet
610mm - 2 Feet
910mm - 3 Feet
